New 2024 Storyteller Overland GXV Hilt

Standard Features (2024)

Ram Chassis Cab

• 5500 Laramie Crew Cab
• 6.7L Cummins Turbo Diesel
• 800 lb-ft torque / 360 hp
• 6-Speed HD Transmission
• Fuel Capacity: 52 gal
• High Idle
• LED Headlamps / Tail Lamps
• Normal Ride Setting:
  • Approach Angle:  33.1°
  • Departure Angle: 20.8°
  • Breakover Angle: 10.8°
• Ground Clearance:
  • Front: 18"(DEF canister)
  • Rear: 10.5"
• High Ride Setting:
  • Approach Angle: 36.3°
  • Departure Angle: 21.5°
  • Breakover Angle: 17°
  • Ground Clearance:
    • Front: 22" (DEF canister)
    • Rear: 10.5"
• Capacities
  • Fuel: 52 gal
  • Fresh water: 120 gal
  • Grey water: 40 gal
  • Black water cassette: 4.75 gal
  • Batteries: 16.8 kWh
  • (2) 3000W inverters
  • Solar: 1325W
  • Seating: 4 cab shoulder belts
  • Sleeping: 2 queen beds

Exterior Features

• Liquid Springs® Smart Suspension System:
  • Liquid Springs Smart Suspension System evaluates speed, steering, braking and ride height 1,000x per second to automatically optimize your ride quality, handling characteristics, and peace of mind.
• 3 ride heights and 3 performance modes selectable on the fly
• 7.5” total travel
• Hutchinson® wheels with 41” Multi Purpose Tires:
  • 3 piece bead lock wheels capable of extremely low psi without de-beading
  • Full-size spare with electric winch system
• Onboard air system, dual air chucks with dual ARB compressors and 1 gal tank
• Rugged custom BuckstopTM bumper
• High pressure spray-on bedliner
• 20k lb winch with synthetic rope
• Extreme 360° lighting package:
  • (8) 10” KC HiLiTES® perimeter light bars
  • (5) 8” KC HiLiTES® front lights
  • (2) bumper mounted KC HiLiTES® fog lights
  • (2) bumper mounted KC HiLiTES® spot lights
• (2) nVader rear storage racks
• (3) Lockable cargo hatches and large lockable pass-through storage area
• 13’ Dual pitch awning
• Automatic entry electric steps

Interior Features

• Sleeps 4 adults:
  • Rear dinette converts to queen size bed
  • Queen size bed in front loft area
  • Assist ladder for loft bed
• Storage:
  • 5 galley storage drawers and pull-out trash bin
  • Upper cabinet storage
  • Storage boxes in loft area with phone chargers
• Touchless black cabinets with wood grain highlights
• Gloss white walls
• Dinette with seating for 4 adults
• MISSION Control full color touchscreen display

Bath

• 120 gal fresh water, 40 gal grey water (electrically heated)
• Wet bath with shower and sink
• Flushable cassette toilet
• Exhaust fan
• Dry storage, mirror, retractable clothes line

Energy System

• M-Power™ System, 16.8 kWh (powered by Lithionics®)
• (2) 3000W inverters
• High idle on RAMs
• 1325W MerlinTM solar panels
• MISSION Control full color touchscreen display

Heating, Ventilation and Air Conditioning

• 10k Btu hydronic heat system with 2 air handlers
• 15k Btu A/C, Ducted Front and Rear
• 360° closed cell foam insulation
• (2) deluxe exhaust fans w/ built-in rain guard
• Wet bath exhaust fan

Safety

• Smoke / CO Detector
• Fire extinguisher
• Ground fault circuit interrupter
• Locking toilet cassette door

Please see us for a complete list of features and available options!

All standard features and specifications are subject to change.

All warranty info is typically reserved for new units and is subject to specific terms and conditions. See us for more details.

Due to the current environment, our features and options are subject to change due to material availability.
